2ton Capacity Explosion Proof Chain Pneumatic Air Hoist With Reliable And Low Maintenance

produtos

Grua Chain à prova de explosões

2ton Capacity Explosion Proof Chain Pneumatic Air Hoist With Reliable And Low Maintenance

Quantidade mínima:	1 unidade
preço:	999USD
Embalagem Padrão:	madeira compensada
Período de entrega:	3 dias úteis
Método de pagamento:	L/C,T/T
Capacidade de fornecimento:	30 PCS/SEMANA

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem

China

Marca

JCYC

Certificação

Número do modelo

Produto:

Grua de ar de corrente à prova de explosão de 2 toneladas

Garantia:

1 ano

Fonte de energia:

Pressão do Ar

Tipo de funda:

Corrente

Velocidade de elevação:

5m/min

Peso máximo de levantamento:

20T

Altura Máxima de Elevação:

10m

Pressão atmosférica:

0,6 MPa

Destacar:

2ton explosion proof chain hoist

pneumatic air hoist low maintenance

explosion proof hoist with warranty

Descrição do produto

2-Ton Capacity Explosion-Proof Chain Pneumatic Air Hoist

The 5-ton explosion-proof chain pneumatic air hoist represents one of the most ideal lifting solutions globally, widely adopted in industrially developed countries. This advanced lifting equipment enhances safety, improves operational efficiency, and reduces operating costs in demanding industrial settings.

Working Principle & Core Technology

Air hoists operate by converting compressed air pressure into mechanical energy to lift loads. Compared to electric hoists, they offer significant advantages, particularly in hazardous and demanding environments where safety and reliability are paramount.

Key Advantages & Safety Features

Explosion-Proof & Intrinsically Safe: No electric sparks generated, completely eliminating explosion risks. Meets Hazardous Area Class I requirements including IIC gas group, T5 and below.
High Efficiency & Continuous Operation: Suitable for continuous operation with 100% duty cycle without overheating concerns.
Superior Environmental Resistance: Highly resistant to acid, alkali, steam, high humidity, and heavy dust conditions.
Compact & Lightweight Design: Weighs only 1/3 to 1/8 of equivalent capacity electric hoists.
Precise Positioning Control: Pull-rod control enables centimetre-level positioning with zero impact for accurate load placement.
Clean & Eco-Friendly Operation: Internal lubrication system prevents air pollution.
Reliable & Low Maintenance: Robust structural design ensures stable performance and minimal maintenance requirements.
Enhanced Safety Protection: Built-in air protection prevents sudden load drops during air supply interruptions.

Technical Specifications

Model	Unit	HQ1-2	HQ2-2	HQ3-1	HQ5-2	HQ8-2	HQ10-2	HQ12-2
Atmospheric pressure	Mpa	0.6	0.6	0.4	0.6	0.4	0.6	0.4
Capacity	Tons	1	2	3	5	8	10	12
Chain numbers	Numbers	2	2	1	2	2	2	2
Motor Power	KW	1.0	1.0	1.8	3.5	1.5	2	1.8
Lifting height	M	Standard lifting height is 3m
Full load lifting speed	m/min	3.6	2.7	2.5	5	1.2	1.5	1
No load lifting speed	m/min	7	5.5	6	10	1.2	2.8	1
Full load descent speed	m3/min	8	7	7.5	10.5	2.5	3.2	2.8
Full load air consumption - Lifting	m3/min	1.2	1.2	2	4	1.5	2.6	2
Full load air consumption - Descent	m3/min	1.5	1.5	3.5	5.5	2.2	3.6	2
Standard weight	kg	32	38	86	79	115	115	119
Noise at full load - Lifting	dB	74	78	74	78	74	78	74
